Automotive wheel hub assembly 43200-50Y00


1. Automotive Wheel Hub Assembly
Automotive wheel hub assemblies are mounted to the holding bracket from the chassis on the axle side and the wheel is mounted to the bolts of the wheel hub assembly on the disc side.

It is an automotive part used in most cars and passenger vehicles.

XYYP now mass-produces wheel hub assembly on a global scale to deliver diverse generations of wheel hubs to OEM customers and aftermarket worldwide.


2. XYYP Automotive Wheel Hub Assembly 43200-50Y00





BCA NO.	OEM NO.	SKF NO.	REF NO.	Vehicle Application	Position
512025	43200-4B000     43202-50Y00    43200-0M000 43200-50Y05 43200-50Y00	BR930134	HUB08027 27BWK04	NISSAN	REAR




SPECIFICATION	VIHICLE APPLICATION
Flange Diameter: 5.28 In. Bolt Circle Diameter: 3.94 In. Wheel Pilot Diameter: 2.05 In. Brake Pilot Diameter: 2.05 In. Flange Offset: 2.07 In. Hub Pilot Diameter: 2.45 In. Bolt Size: M12X1.5 Bolt Quantity: 4 Bolt Hole qty: N/A ABS Sensor: No Number of Splines: N/A	1. NISSAN       •  100 NX B13 1990 - 1996       •  Almera N15 1995 - 2000       •  Sunny Y10 1990 - 2000            •  Sunny N14 1990 - 1996       •  200SX 1995 - 1996       •  Sentra 1991 - 1996


                                                                                                           More wheel hub assemblies...

3. XYYP Automotive Wheel Hub Assembly Feature


◆ 1 year or 30,000 km Warranty

◆ ABS sensors available

◆ Less maintenance required integrated design

◆ Consisting of fewer parts, which are facile for assembly

◆ OEM service available

◆ Passed TS16949


4. XYYP Packing Details
1). Plastic bag + Single white / color box + Carton + Pallet / Plywood box
2). Plastic bag + Single white / color box + Plywood box
3). According to your demand

5. XYYP Automotive Wheel Hub Assembly Export Market
North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe
