Automotive wheel hub assembly 513017K


1. Automotive Wheel Hub Assembly
Automotive wheel hub assemblies are mounted to the holding bracket from the chassis on the axle side and the wheel is mounted to the bolts of the wheel hub assembly on the disc side.

It is an automotive part used in most cars and passenger vehicles.

XYYP now mass-produces wheel hub assembly on a global scale to deliver diverse generations of wheel hubs to OEM customers and aftermarket worldwide.


2. XYYP Automotive Wheel Hub Assembly 513017K








BCA NO.	OEM NO.	SKF NO.	REF NO.	Vehicle Application	Position
513017K	7470014     7466925 7466997 7470004	BR930028K	RW428	BUICK CADILLAC CHEVROLET OLDSMOBILE PONTIAC	FRONT




SPECIFICATION

VIHICLE APPLICATION

Flange Diameter: 4.921 In. Bolt Circle Diameter: 3.937 In. Wheel Pilot Diameter: 2.244 In. Brake Pilot Diameter: 2.295 In. Flange Offset: 1.749 In. Hub Pilot Diameter: 2.894 In. Hub Bolt Circle Diameter: 3.858 In. Bolt Size: M12X1.5 Bolt Quantity: 5 Bolt Hole MET: 12.96 Bolt Hole qty: 3 Flange Shape: MODIFIED TRIANGLE ABS Sensor: No Number of Splines: 33

1. BUICKSkyhawk 1985-1989         •  Skyhawk 1984 2nd Design, 12mm Hole in Mounting FIange         •  Skylark 1986-1998       •  Somerset Regal 1985     2. CADILLAC       •  Cimarron 1985-1988       •  Cimarron 1984 2nd Design, 12mm Hole in Mounting FIange     3. CHEVROLET       •  Beretta 1987-1996       •  Cavalier 1985-2005       •  Cavalier 1984 2nd Design, 12mm Hole in Mounting FIange       •  Corsica 1987-1996     4. OLDSMOBILE       •  Achieva 1992-1998       •  Calais 1985-1987       •  Cutlass Calais 1988-1991       •  Firenza 1985-1988       •  Firenza 1984 2nd Design, 12mm Hole in Mounting FIange     5. PONTIAC       •  Grand Am 1985-1998       •  J2000 1986       •  J2000 1984 2nd Design, 12mm Hole in Mounting FIange       •  J2000 Sunbird 1985       •  Sunbird 1986-1994       •  Sunfire 1995-2005       •  Tempest 1987-1991 Canadian Model


                                                                                                           More wheel hub assemblies...

3. XYYP Automotive Wheel Hub Assembly Feature


◆ 1 year or 30,000 km Warranty

◆ ABS sensors available

◆ Less maintenance required integrated design

◆ Consisting of fewer parts, which are facile for assembly

◆ OEM service available

◆ Passed TS16949


4. XYYP Packing Details
1). Plastic bag + Single white / color box + Carton + Pallet / Plywood box
2). Plastic bag + Single white / color box + Plywood box
3). According to your demand

5. XYYP Automotive Wheel Hub Assembly Export Market
North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe
